TMT Mini 2

For Small & Medium Channel Letters

Don’t let its small size fool you!

The Game Changer Mini Series is engineered to reduce your overall system cost while raising your quality standards allowing you to deliver brighter, better-looking channel letters to your customers with less energy and fewer modules.

• The new 1 Watt module sets a new standard in the industry, combining maximum brightness with ultra-efficient energy use, making it ideal for large-scale or high-impact channel letter projects.

Features

  • Up to 178 Lm/W
  • Innovative Cable Hiding Technology
  • High Efficiency Circuit Design
  • Small Module Footprint of 1.93" x .55"

Applications

  • Ideal for 2-6" Deep Channel Letters and Cabinets
  • Ideal for Any Application Requiring Small Footprint
mini-2-home
mini-2-0
mini-2-1
mini-2-3
TMT MINI 2
FOR SMALL CHANNEL LETTERS
UP TO
10 YEAR
WARRANTY
UP TO
178 Lm
PER WATT
12-24 V
POWER OPTIONS
160°
BEAM ANGLE
TMT Mini 2

Technical Specifications

Operating Temperature:
-22°F to +140°F
Body Material:
Case: ABS | Optics: Optical PC
Finishing:
Ultrasonic Welding
Lifetime (Tm21):
>60,000 Hours
Adhesive Tape:
3M Foam
Strip Size:
50 Modules / Strip

Product Models

Watt Grade CCT / Color Order Code Input Lumen Efficiency C2C 60W PS Load Module / Foot Lumen / Foot Watt / Foot
0.6 W GOLD 6.500K TMT-105712 12V 107 LM 178 LM/W 5.9” 85 PCS 2 PCS 214 LM 1.20 W
0.8 W 6.500K TMT-105713 12V 135 LM 169 LM/W 5.9” 64 PCS 2 PCS 270 LM 1.6 W
1 W SILVER 10.000K TMT-106429 12V 165 LM 165 LM/W 5.9” 51 PCS 2 PCS 330 LM 2 W
8.000K TMT-107573 12V 165 LM 165 LM/W 5.9” 51 PCS 2 PCS 330 LM 2 W
6.500K TMT-107156 12V 165 LM 165 LM/W 5.9” 51 PCS 2 PCS 330 LM 2 W
3.000K TMT-107652 12V 155 LM 155 LM/W 5.9” 51 PCS 2 PCS 310 LM 2 W
RED TMT-107388 12V 47 LM 47 LM/W 5.9” 51 PCS 2 PCS 94 LM 2 W
GREEN TMT-107386 12V 103 LM 103 LM/W 5.9” 51 PCS 2 PCS 206 LM 2 W
AMBER TMT-107669 12V 113 LM 113 LM/W 5.9” 51 PCS 2 PCS 226 LM 2 W
BLUE TMT-107387 12V 35 LM 35 LM/W 5.9” 51 PCS 2 PCS 70 LM 2 W
6.500K TMT-107670 24V 165 LM 165 LM/W 5.9” 51 PCS 2 PCS 330 LM 2 W
